Raised Expanded Metal Sheet

Get Latest Price

Contact Now

Product Description

Product Attributes

Packaging & Delivery

Product Description

Product Attributes

Brand: JoyLink

Material: Galvanized Steel Wire, Stainless Steel Wire

Processing Service: Punching, Cutting

Packaging & Delivery

Selling Units

Others

The file is encrypted. Please fill in the following information to continue accessing it

Product Description

About JoyLink

JoyLink is professionally engaged in production and sales of Wire Mesh Fence,wire mesh series, wire mesh cages and metal wire.

Main products:

Mesh:Welded Wire Mesh,cahin link mesh and fence,hexagonal wire mesh,Expanded Metal Mesh......

Wire:galvnaized wire,annealed wire,Barbed Wire ,razor barbed wire......

Fence:3D curved fence,Chain Link Fence,Double Wire Fence, 358 Fence ......

Construction:Fiberglass Mesh,pvc corner bead

We have more than 80 staffs, and our factory covers an area of 2,000 square meters. We possess about 10 sets advanced production line and 3 sets for quality test. There are six wire mesh factories and 1000 square meters warehouse.

Raised Expanded Metal goes through a process of slitting and stretching metal sheet to form the standard or regular style of expanded metal. The expanded metal now has strands and intersecting strands called bonds forming a sharp angle to the original plane of the solid sheet. This process creates the unique pattern and allows a single sheet of metal to be processed into several sheets of expanded metal.

Raised expanded metal is a highly versatile material created by slitting and stretching metal sheets to form a pattern of diamond-shaped openings. This process provides numerous benefits and applications across various industries.

Key Features and Benefits

Strength and Durability: Raised expanded metal is structurally stronger than other types due to its design, which distributes weight evenly. It can support significant loads, making it ideal for heavy-duty applications
Customizable Design: The characteristics of raised expanded metal can be tailored based on the pattern size and the degree of expansion applied, allowing for control over the percentage of open area. This adaptability enables optimal airflow and light passage in various applications
Cost-Effectiveness: The manufacturing process generates minimal waste, making raised expanded metal a cost-effective solution for many projects. Its longevity also reduces replacement and repair costs over time
Environmental Benefits: The production of expanded metal is environmentally friendly, as it utilizes raw materials efficiently and is recyclable

Style	Lbs.	Design Sizes		Opening Size		Approx. Strand Size		Overall Thickness	Approx. No. Diamonds		Open Area
Style	Per 100 sq. ft.	(Inches)		(Inches)		(Inches)		(Inches)	Per Ft.		%
		SWD	LWD	SWO	LWO	Thickness	Width		SWD	LWD
1/4 x #20	86	0.25	1	0.125	0.718	0.036	0.072	0.135	48	12	45
1/4" x #18	114	0.25	1	0.11	0.718	0.048	0.072	0.147	48	12	43
1/2" x #20	43	0.5	1.2	0.438	0.938	0.036	0.072	0.14	24	10	80
1/2" x #18	70	0.5	1.2	0.438	0.938	0.048	0.088	0.172	24	10	72
1/2" x #16	86	0.5	1.2	0.438	0.938	0.06	0.087	0.175	24	10	65
1/2" x #13	147	0.5	1.2	0.312	0.938	0.09	0.096	0.204	24	10	57
3/4" x #16	54	0.923	2	0.813	1.75	0.06	0.101	0.21	13	6	78
3/4" x #13	80	0.923	2	0.75	1.688	0.09	0.096	0.205	13	6	76
3/4" x #10	120	0.923	2	0.75	1.625	0.09	0.144	0.29	13	6	72
3/4" x #9	180	0.923	2	0.688	1.562	0.134	0.15	0.312	13	6	68
3/4" x #16	44	1	2.4	0.938	2.06	0.06	0.087	0.192	12	5	82
1-1/2" x #16	40	1.33	3	1.25	2.625	0.06	0.108	0.23	9	4	85
1-1/2" x #13	60	1.33	3	1.188	2.5	0.09	0.105	0.242	9	4	85
1-1/2" x #10	79	1.33	3	1.188	2.5	0.09	0.138	0.284	9	4	80
1-1/2" x #9	120	1.33	3	1.125	2.375	0.134	0.144	0.312	9	4	76
1-1/2" x #6	250	1.33	3	1.11	2.375	0.194	0.203	0.433	9	4	69

Common Applications

Raised expanded metal is utilized in a wide range of applications, including:

Metal Grates: Used for flooring in industrial settings, providing slip resistance and durability.
Security Fencing: Offers protection while allowing visibility and airflow.
Architectural Panels: Used in building facades and interior design for aesthetic appeal.
Walkways and Ramps: Provides a sturdy surface for pedestrian traffic, often in outdoor or industrial environments
Machine Guards: Protects equipment while allowing visibility and airflow around machinery

Material Options

Raised expanded metal is available in various materials, including:

Stainless Steel: Offers corrosion resistance and strength.
Aluminum: Lightweight and resistant to rust, suitable for many applications.
Carbon Steel: Provides high strength at a lower cost, often used in industrial settings

Overall, raised expanded metal serves as an effective solution across numerous sectors due to its strength, versatility, and cost efficiency.
